SanDisk Professional G-RAID 2 24TB 2-Bay RAID Array SDPH62H-024T-NBAAD
Overview :
Designed to provide flexibility and reliability for demanding applications, the G-RAID 2 24TB 2-Bay RAID Array from SanDisk Professional is a fast, high-capacity storage solution that supports multi-stream HD, 2K, 4K, and HDR video workflows. Equipped with an overall capacity of 24TB that is made of up 2 x 12TB 7200 rpm Ultrastar Enterprise-class hard drives, the G-RAID 2 delivers data transfer speeds of up to 500 MB/s. In terms of connectivity, this array is equipped with two 40 Gb/s Thunderbolt 3 ports, one 5 Gb/s USB-C port, and one HDMI port. While host connectivity is achieved using one of the Thunderbolt 3 ports or the USB-C port, the second Thunderbolt 3 port remains available for daisy-chaining up to five additional devices, including drives, 4K displays, and more, all through a single cable connection.
SanDisk Professional built the G-RAID 2 with a hardware RAID controller that supports RAID 0, which provides enhanced performance, and RAID 1, which supports 1:1 drive mirroring, although this halves the total capacity. For those who do not need a RAID, JBOD is also available. The system comes preconfigured as RAID 0 and formatted for macOS 10.15 and later, although the system may be reformatted for Windows 10. Included is a 20 Gb/s Thunderbolt 3 cable, a USB-C to USB-A cable, a power cable, and an AC power adapter, while protection is provided by a limited 5-year warranty.
General Features
Enterprise-Class, 7200 rpm Hard Drives Inside
For all your demanding workloads and mission-critical content, you can rely on the power and enhanced reliability of the enterprise-class 7200 rpm Ultrastar hard drives inside.
Daisy-Chaining for up to 5 Additional Devices
With dual Thunderbolt 3 ports, you can conveniently daisy chain up to 5 additional devices to stay connected to multiple drives, 4K displays, and more, through a single connection to your computer.
Built-In Hardware RAID
For maximum performance, the G-RAID 2 comes ready to go in RAID 0 and can be configured to RAID 1 (mirroring) or JBOD for ultimate flexibility.
High-Speed Data Transfers
Quickly back up and move your HD photos and 4K footage with high-speed data transfer rates up to 500 MB/s.
Premium, All-Aluminum Enclosure
With a premium, anodized aluminum enclosure, the G-RAID 2 pairs beautifully with your high-end computer and gives you durable strength you can feel.
Limited 5-Year Warranty
Backed by a limited 5-year warranty, you can be confident in the reliable storage of the G-RAID 2 for years to come.
Specification :
| Drives | |
| Storage Capacity | 24 TB |
| Included Drives | 2 x 12 TB 3.5″ HDD |
| Initial RAID Configuration | RAID 0 |
| Interface | SATA III |
| Rotational Speed | 7200 rpm |
| General | |
| Number of Bays | 2 x 3.5″ |
| Pre-Format | APFS |
| Inputs/Outputs | 2 x USB-C Thunderbolt 3 (40 Gb/s) |
| 1 x USB-C 3.0 / 3.1/3.2 Gen 1 | |
| 1 x HDMI | |
| Compatible Drive Interface | SATA III |
| Form Factor | Desktop |
| RAID | RAID 0, 1, JBOD |
| Transfer Rates | 500 MB/s (Read/Write) |
| UASP Support | No |
| Software | |
| OS Compatibility | macOS 10.15 or Later |
| Windows 10 or Later | |
| *As of February, 2023: Check with manufacturer for the most up-to-date compatibility | |
| Security | |
| Encryption | None |
| Electrical | |
| Power Source | AC Adapter |
| Environmental | |
| Operating Temperature | 41 to 95°F / 5 to 35°C |
| Physical | |
| Cooling | 1 x Fan |
| Material of Construction | Aluminum |
| Dimensions | 9.88 x 5.12 x 3.58″ / 25.1 x 13 x 9.09 cm |
| Weight | 6.2 lb / 2.8 kg |
| Packaging Info | |
| Package Weight | 8.565 lb |
| Box Dimensions (LxWxH) | 11.9 x 8.7 x 6.7″ |
